cat eyes reflective for walkway heavy duty
Solar Road Stud has been designed and manufactured to withstand particular difficult environmental and traffic conditions. The high intensity ABS used is one of those offering maximum compression resistances to vehicular traffic and to spread the impact load over the pavement surface. Reflective lenses use PMMA imported from Japanese. Strong compression resistance, greater than 160KN. Strong reflective, good water-resistance and push-resistance The reflective solar road stud are particularly suitable for roads with heavy traffic.
Solar Road Stud has been designed and manufactured to withstand particular difficult environmental and traffic conditions. The high intensity ABS used is one of those offering maximum compression resistances to vehicular traffic and to spread the impact load over the pavement surface. Reflective lenses use PMMA imported from Japanese. Strong compression resistance, greater than 160KN. Strong reflective, good water-resistance and push-resistance The reflective solar road stud are particularly suitable for roads with heavy traffic.
Solar spike is a kind of spike, which is set along the road surface and used at night or in rain or fog to indicate the direction of the road. It is composed of reverse reflection material, shell, solar panel, LED and control device. It is a visual induction facility with active luminescence and passive reflection performance, which is usually used in combination with the marking line.
The working principle of solar energy spike, solar panels absorb sunlight during the day, the solar energy into electrical energy stored in the storage devices (batteries or capacitors), in the evening, the electricity automatically converted into light energy storage device (through the photoelectric switch control), through the LED light path outline, induce the driver line of sight.
This cast aluminum reflective solar spike battery, life of more than 10 years, IP68, the solar panel area is larger, charging efficiency increased by 30%, more suitable to press in the road stone such as vehicle pressure does not fall.
When we say road studs, we mean the studs for the highway. Also known as raised road signs.
It is a kind of traffic safety facilities. It is mainly installed in the middle of the road marking line or the middle of the double yellow line to remind the driver to drive according to the lane through its reverse reflection performance. The specifications of the spike are generally 100mm*100mm*20mm, and the maximum height is not more than 25mm.
There are a variety of reflectors, reflectors, reflective beads, LED light, reflective film and so on.
According to the material can be divided into:
1. Cast aluminum road studs;
2. Plastic road studs;
3. Glass road studs;
4. Solar road studs;
Body material | Hi-pressure Casting Aluminum alloy |
Power supply | Mon crystalline solar panel,2.5V/120MA for NI-MH;5V/60MA for lithium battery; |
Battery | NI-MH 1.2V/ 600mah(high temperature resistance); Lithium battery 3.2V/500MA(made in Japan); |
LED | Ultra bright diameter 5mm(4pcs or 6pcs) |
LED color | Red,Yellow,Green,Blue,White |
working mode | Recharging at day and working automatically at night |
Working hours | (1).Blinking:140hours for NI-MH battery; 130hours for lithum battery. (2).Constant:40hours for NI-MH battery; 35hours for lithium battery. |
Life span | 3years for NI-MH battery; 5years for Lithium battery |
Visual distance | >800m |
Water proof | IP68 |
Resistance | >20T |
Carton size | 37*30*22cm |
Carton Weight | 17.5KGS/Carton |
