Highway LED Solar Road Stud China Supplier

During the day, solar panels absorb sunlight and convert solar energy into electrical energy, which is stored in energy storage devices (batteries or capacitors). At night, the electrical energy in the energy storage devices is automatically converted into light energy (controlled by photoelectric switches) and emitted by LEDs. Bright light outlines the road and induces the driver’s sight. Solar road studs will start automatically to flash when night falls or with the onset of inclement weather. The bright flashing LEDs are highly effective at getting the attention of drivers much earlier than conventional road studs.

Share:
Content

Application:

Solar road studs are improved and innovated on the basis of traditional cat-eye reflective road signs, mainly to develop the field of road traffic safety, with the purpose of improving road safety and reducing the probability of traffic accidents. At the same time, it can also be used in other fields, such as courtyard decorative lighting, square landscape lighting, etc.

Highways: Road studs are used on highways and roads without street lights on-road sections without isolation belts and insufficient night light.
Landscape lighting: Led solar road studs can also be used as marker light for park paths and decks of boats or bridges.
Crosswalks: Solar-powered road stud work for urban sidewalks, crosswalks(pedestrian crossings)roundabouts, and traffic islands.
Entrance of roads: Solar reflective road studs can be used for high-speed toll entrances to guide vehicles in and out.

Highway LED Solar Road Stud China Supplier
Highway LED Solar Road Stud China Supplier

SPECIFICATION:

Body material : Cast Aluminum
Power supply: 5V/60mAh Monocrystalline silicon
Battery: Lithium battery3.2V/1000mAh
LED: 3pcs/side φ5mm super brightness LED
LED Color: White Green Red Yellow Blue
Flashing model:  flashing  or constant
Working hours: 180 hrs for flashing modes,40hrs for steady modes
Visual distance: 1000m(approx)
Waterproof: IP68
Load Capacity >40T(can be installed in the middle of road)
Size: φ125*50mm   (φ4.92″*1.97″)
Package:  1pcs/box; 30pcs/ctn; weight: 30kgs; Carton size: 67.5*28*20cm

(1pcs/box; 30pcs/ctn; weight: 66.14bs; Carton size: 26.57″*11.02″*7.87″)

Life span: 3-5 years
Working Temperature -25 °C~ + 75°C
waterproof IP68

Highway LED Solar Road Stud China Supplier

Highway LED Solar Road Stud China Supplier

Working Principle of Solar Road Stud Light

During the day, solar panels absorb sunlight and convert solar energy into electrical energy, which is stored in energy storage devices (batteries or capacitors). At night, the electrical energy in the energy storage devices is automatically converted into light energy (controlled by photoelectric switches) and emitted by LEDs. Bright light outlines the road and induces the driver’s sight. Solar road studs will start automatically to flash when night falls or with the onset of inclement weather. The bright flashing LEDs are highly effective at getting the attention of drivers much earlier than conventional road studs.
The base of this solar road stud is made of cast aluminum, and the surface is made of plastic spraying technology.
The product has a rubber bottom pad to increase the service life
The shell is made of reinforced PC material, which has excellent impact resistance and heat stability.
Loading capacity of more than 30 tons, can be used in the middle of the road.
