Highway Plastic Road Stud

NOKIN offers high-quality LED Solar Powered Road Studs, also known as Road Reflectors. These products are designed to guide vehicles and pedestrians for directions. The road reflectors we offer are powered by solar energy, making them more environmentally friendly. Because of their light-feeling function, they automatically light up and help guide people on their way.

Share:
Content

Installation Method Of Raised Solar Road Stud:

Carefully mark the distance between the placement of solar road stud lights. To prevent an adverse effect on the ground, use a proper tool such as Core Drill. Drill 35mm and the depth will be 55mm.
Remove all debris from the installation hole.
Pour epoxy into the holes per the manufacturer’s instruction.
Verify that the installation hole is straight. Verify that the installation hole is large enough to allow the epoxy to surround the solar-led road stud shaft.
Set the lighting surface of the solar road stud to the desired viewing angle. Verify the epoxy is evenly adhering to the installation hole and solar marker shaft. Verify the bottom of the solar road marker is firmly installed on the installation surface allowing for zero surface float; to occur. (space between installation surface and bottom of the solar marker).
After curing the LED solar road stud for 6-8 hours, remove the installation of the isolation facility.
The recommended spacing between each solar road stud is as follows:
Highways and Expressways
7 – 8 yards (5 – 6 meters)
Dangerous Entrances and Exits
4 – 5 yards (2 – 3 meters)
Access or Exit ways for Hospitals, Parking Lots, etc.
0.5 – 3 yards (0.5 – 2 meters)
The spacing between each solar stud is also according to your actual application requirements, the above values are for reference only.
Highway Plastic Road Stud
Highway Plastic Road Stud

SPECIFICATION:

Body material : Cast Aluminum
Power supply: 5V/60mAh Monocrystalline silicon
Battery: Lithium battery3.2V/1000mAh
LED: 3pcs/side φ5mm super brightness LED
LED Color: White Green Red Yellow Blue
Flashing model:  flashing  or constant
Working hours: 180 hrs for flashing modes,40hrs for steady modes
Visual distance: 1000m(approx)
Waterproof: IP68
Load Capacity >40T(can be installed in the middle of road)
Size: φ125*50mm   (φ4.92″*1.97″)
Package:  1pcs/box; 30pcs/ctn; weight: 30kgs; Carton size: 67.5*28*20cm

(1pcs/box; 30pcs/ctn; weight: 66.14bs; Carton size: 26.57″*11.02″*7.87″)

Life span: 3-5 years
Working Temperature -25 °C~ + 75°C
waterproof IP68
Highway Plastic Road Stud
Highway Plastic Road Stud
NOKIN offers high-quality LED Solar Powered Road Studs, also known as Road Reflectors. These products are designed to guide vehicles and pedestrians for directions. The road reflectors we offer are powered by solar energy, making them more environmentally friendly. Because of their light-feeling function, they automatically light up and help guide people on their way.
Our LED Solar Powered Road Studs are rated as IP68. They are fully dust-tight and protected from long-term immersion in water. They can withstand up to a specified pressure, and they have limited ingress protection. These lights also come in different colors such as red, green, yellow, white, and blue.
These pieces of lighting equipment signify our commitment to providing quality products to each and every household or business in the Philippines. We continually strive to provide easy access to energy-efficient and environmentally friendly lighting alternatives that are set at reasonably low and affordable prices.
If you need a product recommendation or design inspiration for your projects, you may check out our Completed Lighting Project page for ideas.
For inquiries regarding our products and services, you may also send us an e-mail or contact us through our mobile numbers.
