NOKIN Motorway Flashing Solar Road Stud Light

Shenzhen NOKIN traffic facilities Co., Ltd is an innovative technology company for overseas personnel. Professional institutions of professional and technical development in road stud light and LED traffic products. Is a set of product development, production, sales, and integration of high-tech enterprises, the company’s main products are involved in solar traffic signal lamps, tunnel, tunnel-induced photoelectric products, solar road stud lights, solar LED full set of road signs instructions.

Share:
Content

Installation Method Of Embedded Solar Road Studs

1. Mark the proper installation position. Usually, a 3m distance between road studs will be better.
2. Use the core drilling machine to drill a hole according to the actual size of the shark. Dry the holes with a blowtorch and clean their hole.
3. The epoxy value ratio: Of a glue and B glue is 1: 1. The cement should be mixed well-distributed with the electric drill, 40-50g will be used for each
4. Pour the glue into the hole, get to three-quarters of the hole: Clean the bottom of the solar stud and put it into the hole.
5. Use the knife to clean the surrounding overflow glue after the installation and re-mover all debris from the carriageway.
6. Wait 8 hours for drying before activating the solar stud.
The spacing between each solar stud is also according to your actual application requirements, the above values are for reference only.
NOKIN Motorway Flashing Solar Road Stud Light
NOKIN Motorway Flashing Solar Road Stud Light

SPECIFICATION:

Body material : Aluminum Alloy+PC cover
Power supply: Solar panel(Monocrystalline 5V /80MA)
Battery: Lithium battery 1000MAH*3.2V
LED: Ultra bright diameter 5mm*6PCS
LED Color: White Green Red Yellow Blue
Flashing model:  flashing  or constant
Working hours: 140 hrs for flashing modes,40hrs for constant modes
Visual distance: 1000m(approx)
Waterproof: IP68
Load Capacity >30T(can be installed in the middle of  the road)
Size: φ123*45mm  (φ4.84″*1.77″)
Package:  1pcs/box; 30pcs/ctn; Weight: 30kgs; Carton size: 67.5*28*20cm

(1pcs/box; 30pcs/ctn; Weight: 66.14bs; Carton size: 26.57″*11.02″*7.87″)

Life span:  more than 5 years
Working Temperature -20 °C~ + 70°C
waterproof IP68
