Plastic Road Stud Marker For Port

Solar road stud marker installation is not a complicated matter, but there are many details that require attention. These details play an important role in ensuring the quality and service life of road stud markers. This is most important, please placed in isolation facilities installation safety first, then everyone should be in the safe facility when installing. Determine the installing location. To ensure the installation location is smooth, should level scalable, cracks, uneven pavement first, also please be sure the solar panel is being shined by sunlight.

Share:
Content

Plastic Road Stud Marker Description

Solar Panel 2V/200MAH mono-crystalline silicon
Battery 1.2V/1500MAH anti-high temperature Li-ion battery
Lighting time 100 hours after fully charged
Work Mode flash, stable or customized
LED Color red/yellow/blue/green/white
LED Qty 12pieces diameter 5mm high brightness Taiwan Epistar LED light
Visibility >1000m
Life Span 3-5 years
Work Temperature -20℃~+80℃
Material anti-UV PC
Size 114*90*11mm
N.W 250g
Certifications IP68/CE/RoHS
Weight Resistantance >15tons



solar led road stud

Plastic Road Stud Marker Application:

1. Mainly used for the tunnel, turnoff.

2. school gate, accident-prone highway, or bend.
3. Foggy area (seaside, airport area), highway or non-street light area.
4. The ramp , curve or some dangerous roads.



raised solar road stud Q7





Plastic Road Stud Marker Installation:

Solar road stud marker installation is not a complicated matter, but there are many details that require attention. These details play an important role in ensuring the quality and service life of road stud markers.

1. This is most important, please placed in isolation facilities installation safety first, then everyone should be in the safe facility when installing.

2. Determine the installing location. To ensure the installation location is smooth, should level scalable, cracks, uneven pavement first, also please be sure the solar panel is being shined by sunlight.

3. To ensure the installation location dry, should clean up it with a brush,

4. Evenly apply appropriate glue on the spike;

5. Firmly press the spike on the installation location in the right direction, if the glue is more, please must clean it up;

6. If it is an aluminum alloy with a pillar, the hole depth must be 1cm deeper than the pillar, hole diameter must be 2mm larger than the pillar diameter.

7. After installing, please check it every 2h, to ensure that all the spikes are installed at the right direction and good condition.

8. After the glue curing for 4 hours, removed installation isolation facilities.



Plastic Road Stud Marker For Port



Plastic Road Stud Marker

Plastic Road Stud Marker

FAQ

Q1. What’s the MOQ?
It’s 10pcs, but if you need less, it’s ok, but the price will be changed based on your quantity.

Q2.What is your quality warranty?
All of our models are with 1 years quality warranty.

Q3. What’s the lead-time for orders?
Normally it takes 5 working days after receiving payment.

Q4. How long will the solar road stud marer work during Rainy and Foggy day?

Solar Road Stuc can work 5-7 rainy and foggy day after full charge.

Q5.Can the solar road stud marker can work well in tropical Counties?

The solar road stud marker is equipped with an Anti-high temperature battery. it can work well in -20 to +70.

Q6. Can I have a sample order for the road stud marker?

Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable.

Q7.How do you ship the goods and how long does it take to arrive?

We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
