solar road stud for path IP68

This solar-powered road stud adopts a double-sided luminous design, it is composed of reflective materials, die-cast aluminum shell, solar panels, LEDs, energy storage batteries, and control devices. It combines active luminescence and passive reflection to be road markers. The number of led chips is 4pcs/6pcs optional. It is the most mainstream solar road stud solution currently on the market, is used for deck, highway, crosswalk, lanes by engineering companies, wholesalers, and retailers.

Share:
Content
road stud for path IP68 solar
road stud for path IP68 solar



This solar-powered road stud adopts a double-sided luminous design, it is composed of reflective materials, die-cast aluminum shell, solar panels, LEDs, energy storage batteries, and control devices. It combines active luminescence and passive reflection to be road markers. The number of led chips is 4pcs/6pcs optional. It is the most mainstream solar road stud solution currently on the market, is used for deck, highway, crosswalk, lanes by engineering companies, wholesalers, and retailers.



road stud for path IP68 solar
road stud for path IP68 solar



Feature

  • Led as the main light source+passive reflective material which can mark the direction of the road more clearly and safely. Compared with the traditional cat’s eye road stud, this double-sided solar-powered road stud will be safe and durable. Even if the solar system fails, passive reflection can guide the driver correctly. The visual distance up to 500meter.
  • There is a solar energy control system inside, it can actively control the LED lighting mode and frequency. Steady on or flashing optional.
  • There are five colours for passive reflective materials,yellow(amber),white,blue,red,green.The light-emitting surface can be freely combined with these reflective covers to meet the application needs of various places. The yellow(amber) road stud is the main one for the left edge of a road, the white solar road stud light is for the right edge or middle of the road. The blue solar road will be for emergency places.
  • We use die-cast aluminum as the main body of solar-powered solar road stud light, while resisting aging and corrosion, the static compression capacity can reach 20TONS, you can install it in the middle of the road.
  • Adopting a high-temperature-resistant battery that can work 1000 times in cycles, the road studs can work normally even in harsh environments.
  • Extremely strong waterproof ability(IP66 Waterproof), solar panels, electronic components, and LEDs are in the shell through special sealed technology, it can be used normally for long-term water pavement.
  • High-efficiency monocrystalline silicon solar panels, the conversion rate can be as high as 19%.
  • The service life is 3-5 years.
  • Easy to install, fix it with epoxy glue or screws.
  • We can customize the 2.4G or GPS sync flash function which will make sure all solar-powered road studs will be flashing at the same time.



road stud for path IP68 solar
road stud for path IP68 solar



Installation for solar-powered road stud

(1) Positioning: First determine the installation position with a ruler, and ensure that each position is longitudinally in a straight line. The installation distance and design requirements shall prevail. The installation place shall be flat, dry, clean, and seamless. Use solar road studs or templates to mark out the holes, and drill holes with an electric hammer with a diameter of ∮8mm, with a depth of 5cm. After drilling the hole, clean the dust cover, install the rubber plug into the hole, and level with the road surface.

(2) Mixing glue: A glue for road studs and glue B for solar road studs. The ratio of glue A and glue B is 1:1(for example, glue A is 1 kilogram, glue B is 1 kilogram). We have to keep glue stirred evenly and consistent color.

(3) Screw on the screws with glue: cleaning the road surface during installation, and using moderate glue to stick to the bottom surface of solar-powered road stud without spilling too much. Only use the glue of 40-50grams for each spike. Place the bottom surface of the road marking on the position where the holes are made, and then tighten it with two special screws and rubber plugs. Clean up road debris after installation.

(4) Patrol: You need to check the installed spikes after two hours.

(5) Road closure: We recommend closing the road for 6 hours to ensure the curing time of the glue.



road stud for path IP68 solar
road stud for path IP68 solar
LED Quantities 4leds for double-sided 6leds for two sides
LED Source type F5 LED Chips
Color Amber, Red, Green, Blue, White optional
Materials Die-cast aluminum body+High strength reflective cover
Dimension 105*105*22mm
Solar panel Mono solar panel,2.5V 120mAH
Battery Ni-MH battery 1.2V 600mAH, the Li-battery or capacitor available if needed
Working model Steady on(last 40hours) or Flash (last 300Hrs)
Visual distance >500meters
IP Grade IP66
Working life >3years
Compressive capacity >20Tons
Working environments -20℃~+70℃
Inner Package 2pcs/inner box (120*120*50mm)/0.5KG
Package  400×280×270mm/60PCS/15KG
