solar road stud reflector port tempered glass

Solar Road Stud has been designed and manufactured to withstand particular difficult environmental and traffic conditions. The high intensity ABS used is one of those offering maximum compression resistances to vehicular traffic and to spread the impact load over the pavement surface. Reflective lenses use PMMA imported from Japanese. Strong compression resistance, greater than 160KN. Strong reflective, good water-resistance and push-resistanceThe reflective solar road stud are particularly suitable for roads with heavy traffic.

Share:
Content
solar road stud reflector port tempered glass
solar road stud reflector port tempered glass



Solar Road Stud has been designed and manufactured to withstand particular difficult environmental and traffic conditions. The high intensity ABS used is one of those offering maximum compression resistances to vehicular traffic and to spread the impact load over the pavement surface. Reflective lenses use PMMA imported from Japanese. Strong compression resistance, greater than 160KN. Strong reflective, good water-resistance and push-resistanceThe reflective solar road stud are particularly suitable for roads with heavy traffic.



solar road stud reflector port tempered glass
solar road stud reflector port tempered glass





Solar spike is a kind of spike, which is set along the road surface and used at night or in rain or fog to indicate the direction of the road. It is composed of reverse reflection material, shell, solar panel, LED and control device. It is a visual induction facility with active luminescence and passive reflection performance, which is usually used in combination with the marking line.
The working principle of solar energy spike, solar panels absorb sunlight during the day, the solar energy into electrical energy stored in the storage devices (batteries or capacitors), in the evening, the electricity automatically converted into light energy storage device (through the photoelectric switch control), through the LED light path outline, induce the driver line of sight.
This cast aluminum reflective solar spike battery, life of more than 10 years, IP68, the solar panel area is larger, charging efficiency increased by 30%, more suitable to press in the road stone such as vehicle pressure does not fall.





solar road stud reflector port tempered glass
solar road stud reflector port tempered glass



Body material Hi-pressure Casting Aluminum alloy
Power supply Mon crystalline solar panel,2.5V/120MA for NI-MH;5V/60MA for lithium battery;
Battery NI-MH 1.2V/ 600mah(high temperature resistance);
Lithium battery 3.2V/500MA(made in Japan);
LED Ultra bright diameter 5mm(4pcs or 6pcs)
LED color Red,Yellow,Green,Blue,White
working mode Recharging at day and working automatically at night
Working hours (1).Blinking:140hours for NI-MH battery; 130hours for lithum battery.
(2).Constant:40hours for NI-MH battery; 35hours for lithium battery.
Life span 3years for NI-MH battery;
5years for Lithium battery
Visual distance >800m
Water proof IP68
Resistance >20T
Carton size 37*30*22cm
Carton Weight 17.5KGS/Carton



solar road stud reflector port tempered glass
solar road stud reflector port tempered glass





Solar powered cat eye lights are weatherproof outdoor ground-type lights commonly known as solar road stud lights or cat’s eyes. These are unique traffic safety warning LED lights designed to highlight dangerous zones while requiring little maintenance and generating no ongoing operational costs.

The cat’s eye design originated in the UK, and today it is used all over the world, including Australia. Lights got their name as the lights looked like cat’s eyes showing in each direction. A modern version of the product is equipped with a solar panel that absorbs the sunlight to store the energy in the battery. At night, a special photoelectric sensor automatically switches the LED lights on delivers visibility of a stud light up 1 kilometre.

These road stud lighting devices are widely used in high-risk areas such as winding roads, sharp turns, and limited street lighting. Similarly to road studs, Cat’s eyes can be embedded or installed on the surface. They work efficiently to reduce speed or attract drivers’ attention to pedestrian crossings, hazards, and dangerous bends on highways and other roads. As traffic markers, these LED lights are applicable for various residential and commercial scenarios from home and garden pathways and driveways to sidewalks and pedestrian crosswalks, roundabouts, safety and traffic islands, bike and moto tracks. Solar cat eyes road studs can also be seen in parks lanes, hotel paths, decks and marina docks.
