Square Expressway Solar Road Stud Factory

The Solar Road Stud Light “is simply an” active road stud ” with automatic switching, achieved by combining small solar panels, rechargeable cells, and LED drive circuits. Today, road lighting systems have been widely considered essential to control flow in a large number of applications. In practice, such Solar Road Stud Light systems operate well above the pavement and use multiple well-known and widely accepted colors where lights have specific directions to make a clear message to the driver, thereby improving road traffic while enhancing safety.

Share:
Content

The solar road stud is a kind of road stud, which is set along the road surface and used to indicate the direction of the road at night or in rainy and foggy weather. It is set along the road surface and used to indicate the direction of the road at night or in rainy and foggy weather. It is composed of retroreflective materials, shells, solar panels, LEDs, and control devices. Visual induction facilities with active light-emitting and passive light-reflecting properties are usually the same as those Used in conjunction with markings.

Square Expressway Solar Road Stud Factory
Square Expressway Solar Road Stud Factory

SPECIFICATIONS:

Product Name solar road stud NK-RS-A6B
Body material Hi-pressure Casting Aluminium alloy
Power supply Monocrystalline solar panel 2.5V/0.25W
Battery NI-MH 1.2V/ 600mah or Lithium battery (high-temperature resistance);
LED Ultra bright diameter 5mm 6pcs
LED color Red, Yellow, Green, Blue, White
working mode Recharging at day and working automatically at night
Working hours (1).Blinking:140hours for NI-MH battery;

(2).Constant:40hours for NI-MH battery;

Life span 2 years for NI-MH battery;
Visual distance >800m
Waterproof IP68
Resistance >20T
Size L114*W129*H23mm/122*104*23mm+53mm
Package: 2pc/box;60pcs/ctn
Carton Size:  Without shank: 2pcs/box; 60pcs/ctn; Weight: 21kgs; Carton size:58.5*24.5*18.5cm

(2pcs/box; 60pcs/ctn; Weight: 46.30bs; Carton size:23.03″*9.65″*7.28″)

With shank: 1pcs/box; 45pcs/ctn; Weight: 18.5kgs;  carton size: 56.5*34.8*23.6cm

(1pcs/box; 45pcs/ctn; Weight: 40.79bs; Carton size:22.24″*13.70″*9.29″)

Certificate CE;ROHS;IP68
Square Expressway Solar Road Stud Factory
Square Expressway Solar Road Stud Factory

The Solar Road Stud Light “is simply an” active road stud ” with automatic switching, achieved by combining small solar panels, rechargeable cells, and LED drive circuits. Today, road lighting systems have been widely considered essential to control flow in a large number of applications. In practice, such Solar Road Stud Light systems operate well above the pavement and use multiple well-known and widely accepted colors where lights have specific directions to make a clear message to the driver, thereby improving road traffic while enhancing safety.
